Architecture

SharpLsp separates editor protocol handling from compiler-backed semantic analysis.

graph LR
    Editor([Editor / IDE])

    subgraph T1[Tier 1 — Rust LSP Host]
        direction TB
        LSP[LSP Server\nJSON-RPC over stdio]
        Router[Request Router]
        VFS[Virtual File System]
        TS[tree-sitter\nC#]
        LSP --> Router
        LSP --> VFS
        VFS --> TS
    end

    IPC[[IPC\nMessagePack\nnamed pipes / Unix sockets]]

    subgraph T2[Tier 2 — C# Sidecar]
        direction TB
        Roslyn[Roslyn\nMSBuildWorkspace]
        Decompiler[ICSharpCode.Decompiler]
        CSharpFeatures[completions\ndiagnostics\nrefactoring]
        Roslyn --> Decompiler
        Roslyn --> CSharpFeatures
    end

    subgraph T3[Tier 3 — F# Sidecar]
        direction TB
        FCS[FSharpChecker]
        Project[F# project options]
        FSharpFeatures[completions\ndiagnostics\nrefactoring]
        Project --> FCS
        FCS --> FSharpFeatures
    end

    Editor -- LSP 3.17 --> LSP
    Router -- C# syntax --> TS
    Router -- C# / F# semantics --> IPC
    IPC <--> Roslyn
    IPC <--> FCS

Tier 1 — Rust LSP Host

The host process owns:

• LSP 3.17 JSON-RPC over stdio;
• full-text document synchronization and the in-memory VFS;
• tree-sitter parsing: folding and selection ranges for C# and F#, plus C# document symbols, linked editing, and syntax pre-validation;
• routing to the correct language sidecar;
• sidecar startup, health checks, restart backoff, and shutdown;
• diagnostic delivery, NuGet request handling, and profiler request handling.

The host loads both the C# and F# tree-sitter grammars, so F# folding and selection ranges are served from syntax too. F# document and workspace symbols route to FCS.

Although tree-sitter is designed for incremental parsing, the current full-sync path reparses C# documents from a fresh tree after each change. SharpLsp does not currently depend on salsa.

Tier 2 — C# Sidecar

A long-running .NET 10 process hosts Roslyn and MSBuildWorkspace. It provides C# completion, hover, diagnostics, navigation, references, rename, code actions, semantic tokens, inlay hints, code lens, and hierarchy queries. C# document and workspace symbols are produced by the Rust host's tree-sitter path instead.

A shared ICSharpCode.Decompiler component produces metadata-as-source locations for many BCL and referenced-assembly symbols.

Tier 3 — F# Sidecar

A separate .NET 10 process hosts FSharpChecker. It loads F# project information through SharpLsp's own project/options code and provides F# completion, hover, signature help, diagnostics, navigation, references, rename, symbols, code actions, semantic tokens, inlay hints, code lens, and hierarchy queries.

Fantomas formatting code exists inside the sidecar but is intentionally not routed or advertised by the host. FSharpLint is a dependency but is not connected to the diagnostic pipeline.

IPC

The host communicates with each sidecar using:

• MessagePack payloads;
• named pipes on Windows or Unix domain sockets on Linux and macOS;
• a 4-byte little-endian length prefix;
• correlated request/response envelopes.

A sidecar failure does not take down the host. The lifecycle manager marks the process unavailable, applies restart backoff, and can start a replacement. The replacement does not yet reload the workspace or the open documents (#386), so after a sidecar crash run SharpLsp: Restart Language Server to bring that language's features back.

Request Routing

Formatting is not advertised for either language. Use CSharpier for C# and a dedicated Fantomas integration for F#.

Latency values elsewhere in the project are engineering targets, not guarantees for every repository, machine, or cold-start state.
